Description
Type
Floor / Desktop
Scanning Method
Color CIS
Printing Method
Digital 4 LED Full-color Electrophotographic Printing Method
Copy Density Adjustment
7 levels (Manual)
Input Capacity
Tray 1 : 300 sheets
(Optional)Additional Tray : 535 sheets
Multi-purpose tray : 100 sheets
Scanning Resolution
Up to 600 x 600 dpi
Writing Resolution
Up to 600 x 1200 dpi
Acceptable Original
Sheet, Book
Original Size
Flatbed: A3, A4, A5, A6, B4, B5, Letter, Legal 13, Legal 13.5, Legal 14, Executive, Tabloid (11" x 17"), Statement, Folio, Custom Size: Width 0-297 mm x Length 0-431 mm;
ADF: A3, A4, A5, A6, B4, B5, Letter, Legal 13, Legal 13.5, Legal 14, Executive, Tabloid (11" x 17"), Statement, Folio, Custom Size: Width 105-297 mm x Length 148-431 mm
Copy Paper Size
A3, A4, A5, A6, B4, B5, B6, Letter, Legal 13, Legal 13.5, Legal 14, Executive, Tabloid (11" x 17"), Statement, Folio, 8K, 16K, Envelopes, Postcard, Return postcard, Custom Size: Width 64-297 mm x Length 90-1321 mm
Copy Scaling
25 – 400 %
Maximum Copies
999 sheets
Copy Speed
A4 35 cpm color, 35 cpm mono
First Copy Out Time
Color: Approx. 10.0 seconds, Mono: Approx. 10.0 seconds
Warm-up Time
Approx. 32.0 seconds from power-on
Power Source
Single phase 220 - 240 VAC ±0%, 50/60 Hz ±2%
Power Consumption
Operating: Max. 1,400W / Ave. 850W
Idle: 120W
Power Save: 30.0W
Deep Sleep: 3.0W
Auto-Off: 0.1W
Memory (Std./Max.)
1,280MB/1,280MB
Noise Level
Operating :Approx. 54 dBA
Idle:
Operating Environment
Operating: 10 - 32 °C, 20 - 80 %RH
Storage: 0 - 43 °C, 10 - 90 %RH
No condensation
Dimensions(WxDxH)
563 x 600 x 700 mm
Weight(includes supplies)
Approx. 64.0 kg
Duty Cycle
Recommended: 10,000 pages/month
Maximum: 75,000 pages/month
In the Box
Others, Starter toner cartridge x 4, Image Drum x 4, Power cable, DVD-ROM, Ferrite Core
Print
Print Speed
A4(Landscape) 35 ppm color, 35 ppm mono
A3 20 ppm color, 20 ppm mono
First Print Out Time
Color: Approx. 9.5 seconds
Mono: Approx. 9.5 seconds
Printing Resolution
600 x 600 dpi
600 x 1200 dpi (4 levels)
600 x 600 dpi
Physical dot pitch: 600 dpi
Interface
1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed), (Optional) Wireless LAN (IEEE802.11a/b/g/n), USB 2.0 (High Speed) Host
Protocol
TCP/IP
Printer Language
PostScript 3 emulation, PDF v1.7 emulation, PCL 5c emulation, PCL 6 (XL) emulation, XPS emulation, IBM ProPrinter emulation, Epson FX Emulation
Supported OS (Click here for latest OS)
Windows 8.1, Windows 8.1 x64, Windows 8, Windows 8 x64, Windows 7, Windows 7 x64, Windows Vista, Windows Vista x64, Windows Server 2012 R2, Windows Server 2012, Windows Server 2008 R2, Windows Server 2008, Windows Server 2008 x64, Windows Server 2003, Windows Server 2003 x64, OS X 10.10, OS X 10.9, OS X 10.8, OS X 10.7, Mac OS X 10.6, Linux
Memory (Std./Max.)
1,280MB/1,280MB
Hard Disk Drive
250 GB
Font
Adobe PostScript 80 fonts, PCL emulation 87 scalable fonts, 4 bitmap fonts
Paper Size
A3, A4, A5, A6, B4, B5, B6, Letter, Legal 13, Legal 13.5, Legal 14, Executive, Tabloid (11" x 17"), Statement, Folio, 8K, 16K, Envelopes, Postcard, Return postcard, Custom Size: Width 64-297 mm x Length 90-1321 mm
Paper Weight
Tray 1 : 64 - 220 gsm
(Optional)Additional Tray : 64 - 176 gsm
Multi-purpose tray : 64 - 256 gsm
Input Capacity
Tray 1 : 300 sheets
(Optional)Additional Tray : 535 sheets
Multi-purpose tray : 100 sheets
Output Capacity
Upper tray : Max. 100 sheets
Face Down : Max. 250 sheets
Face Up : Max. 100 sheets
Scan
Scan Resolution
Max. 600 x 600 dpi
Scan Speed
Max. 50 ipm Color, 50 ipm mono
Interfaces
1000BASE-T/100BASE-TX/10BASE-T, USB 2.0 (High Speed), (Optional)Wireless LAN (IEEE802.11a/b/g/n), USB 2.0 (High Speed) Host
Supported Protocol
SMB, FTP(S), TWAIN, WIA2.0
Output Format
Secure PDF, High compression PDF, JPEG, TIFF, XPS
Driver
TWAIN, WIA2.0(Windows Vista or later), ICA(Mac OS X 10.6 or later)
Fax
Applicable Line
PSTN, PBX
Interface
RJ-11 x 2 (Line, Tel)
Transmission Resolution
Normal: 8 dots/mm x 3.85 lines/mm
Fine/Photo: 8 dots/mm x 7.7 lines/mm
Ultra-Fine: 16 dots/mm x 15.4 lines/mm
Communication Speed
Super G3: 33.6kbps
Encoding Method
MH, MR, MMR, JBIG
Communication Mode
ITU-T G3, Super G3
Transmission Original Size
Max. A3, Length 420 mm
Paper Size
Max. A3, Min. A5
Transmission Time
Approx. 2.0 sec. / page
Memory
Max. 400 pages (8MB)
Other Function
Speed Dial(1000 locations), Broadcast(32 group, 100 locations/group), Duplex scanning, F-Code Confidential FAX, Delayed Tx, LDAP, PC Fax, PDF Store/Distribution
Document feeder
Type
Reverse Automatic Document Feeder (RADF)
Original Size
A3, A4, A5, A6, B4, B5, Letter, Legal 13, Legal 13.5, Legal 14, Executive, Tabloid (11" x 17"), Statement, Folio, Custom Size: Width 0-297 mm x Length 0-431 mm
Original Weight
60 - 120 gsm
Loading Capacity
Max. 100 sheets
Original Exchange Speed
Simplex 35 ppm color, 35 ppm mono
Duplex 17 ppm color, 17 ppm mono
